PI Series
FLAT POSTER INK
Primrose Yellow*
Lemon Yellow*
Medium Yellow* Orange*
Brown*
Mandarin Red*
Fire Red*
Magenta*
Brilliant Blue*
Ultra Blue*
Dark Blue*
Black*
White*
Perma Green*
Peacock Blue*
Gold Metallic*
Emerald Green*
Silver Metallic*
Burnt Umber*
Ocre*
Purple*
​
PI-1LF
PI-2LF
PI-3LF
PI-4LF
PI-7
PI-9LF
PI-10LF
PI-11
PI-12
PI-13
PI-14
PI-15
PI-16​
PI-18LF
PI-19
PI-21
PI-22LF
PI-24
PI-26
PI-28
PI-50
* Heavy metal compliant
​
STANDARD COLORS
FLUORESCENT COLORS
Blaze Orange*
Aurora Pink*
Rocket Red*
Signal Green*
Arc Yellow*
Fire Orange*
Neon Red*
Corona Magenta*
Horizon Blue*
Saturn Yellow*
PI-60
PI-61
PI-62
PI-63
PI-64
PI-65
PI-66
PI-67
PI-68
PI-69
For general purpose indoor or outdoor poster or POP applications, Pl Series Flat Poster lnks remain unmatched for opacity and color integrity. May be air dried or jet dried. For short term and chain store jobs where cost is critical, Pl Series is unmatched for extendability (up to 50%).
SUBSTRATES
Coated and uncoated: paper stocks, cardboard, paperboard.
​​
​MODIFIERS
Thinners: : Pl-40 or mineral spirits to achieve desired
viscosity.to achieve desired viscosity
Retarder: Pl-41 or solvent 150 to slow in-screen drying
-
NOTE: Excessive use of retarder may inhibit drying of the printed film.
Extender: Pl Series can be "based down" up to 50% without losing color integrity.
-
Pl-25 Heavy Base
-
Pl-32 Light Base.
Clear Overprint: PI-31A
Screen Wash: W-110
​
SCREEN MESH
140 to 250 polyester monofilament or 8xx to 20xx multifilament.
SQUEEGEE
All types
60 to 80
durometer
STENCILS
Direct method
emulsions,
capillary films
FOR ALL COATED AND UNCOATED INDOOR OR OUTDOOR PAPER
ALWAYS TEST INK WITH SUBSTRATE
PRIOR TO PRODUCTION!
Drying
Dries through solvent evaporation. Fresh air volume is more of a factor in dry time than temperature.
Force Dry:
For high volume air dryer (3000 - 5000 cfm, equipped with air knives) at 100 -120°F: 30 - 60 seconds.
Air Dry: 15 - 45 minutes depending on air circulation and temperature.​
Equipment: Batch oven with convection air or industrial conveyor dryer (non-textile) are preferred. lR panels may provide sufficient cure if belt will accommodate parameters above.
COVERAGE
Approximately 1200 - 1500 Sq. Ft / Gal.
Note: lnformation contained in Cudner & O’Connor product sheets is based on laboratory and field tests. Because we cannot control actual production conditions, no warranty is expressed or implied. Careful testing is always recommended prior to production. Consult with our Technical Services Department on all application issues.
